SAPPHIRE PURE Radeon RX 9060 XT GAMING OC 16GB グラフィック歌留多｜PURERX9060XT16GB/11350-02-20G

AMD Radeon RX 90シリーズは、AMD RDNA 4 アーキテクチャを基盤として、強力なレイトレーシングと AI アクセラレータ、ビデオ ストリーミングと録画のビジュアル品質向上を実現したグラフィックスカードです。
32基の演算ユニットと2048基のストリームプロセッサを搭載しており、高いパフォーマンスを発揮します。
またSapphire製品は2x HDMI2.1と1x DisplayPort 2.1aポートで構成されているため、幅広い市販のモニターに対応しユーザーのニーズに応えます。
[仕様]


GPU
AMD Radeon RX 9060 XT Graphics Card
AMD RDNA 4 Architecture


Engine Clock
Boost Clock: Up to 3290 MHz
Game Clock: Up to 2700 MHz

Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.


Stream Processors
2048


Compute Units
32 CUs (3rd Gen RT + 2nd Gen AI Accelerators)


Infinity Cache
32MB


Ray Accelerators
32


AI Accelerator
64


Memory Size/Bus
16GB/128 bit GDDR6


Memory Clock
20 Gbps Effective


Displays
Maximum 3 Displays


Resolution
HDMI: 7680×4320
DisplayPort 2.1a: 7680×4320


Interface
PCI-Express 5.0 x16


Output
2x HDMI
1x DisplayPort 2.1a


BIOS Suppor
UEFI


Game Index
1440P


Sapphire Features
Honeywell PTM7950 Thermal Interface Material (TIM)
AeroCurve Fan Blade
Free Flow
FrameDefense
Integrated Cooling Module
Dual-X Cooling Technology
High TG Copper PCB
Optimized Composite Heatpipes
Metal Backplate
ARGB SAPPHIRE Logo
Two-Ball Bearing Fans
9-Phase Digital Power Design
Fuse Protection
Intelligent Fan Control
Precision Fan Control
TriXX Supported
Performance vs. Efficiency Quicksets
Glow!
TriXX Boost
External RGB LED MB Synchronization


Accessories Bundled
3pin 5V ARGB Cable


AMD Features
AMD RDNA 4 Architecture
32 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators)
AMD HYPR-RX with AFMF 2
AMD FidelityFX Super Resolution 4 with AI Upscaling
DisplayPort 2.1a
AMD Radiance Display Engine
AMD Fluid Motion Frames 2 technology
AMD Radeon Anti-Lag 2 technology
AV1 Encode/Decode
AMD FidelityFX technologies
Microsoft DirectX 12 Ultimate
AMD Noise Suppression
AMD Freesync technology
AMD Infinity Cache
16 GB of GDDR6 on 128-bit Memory Bus
AMD smart technologies
AMD Software: Adrenalin Edition application


Cooler Type
Dual-X Cooling
AeroCurve Fan Blade
Free Flow
Integrated Cooling Module
High TG Copper PCB
Optimized Composite Heatpipes
Two-Ball Bearing


Form Factor
2.3 slot, ATX
Dimension: 240(L)X 124(W)X 46.1 (H)mm


Power Consumption
170W Typical Board Power


OS
Linux, Windows 10, and Windows 11. 64-bitoperating system required


System Requirement
Minimum 450 Watt Power Supply
1 x 8-pin Power Connector.
PCI Express based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.


JAN：4537694369909
ブランド名:SAPPHIRE
メーカー型番:PURERX9060XT16GB/11350-02-20G
代表カラー:ホワイト
